Mini Combi Steam Oven 6-Layer 6-Tray for Cafes and Restaurants
SKU: HM-1
| Specification | Details |
|---|---|
| Model | 6-Layer 6-Tray Touchscreen Universal Steam Oven AWE-0623B-M2 |
| Brand | Axewood |
| Manufacturer | Guangzhou Golden Armor Catering Equipment Co., Ltd. (Sino-Joint Venture) |
| Place of Origin | Guangzhou, China |
| Heating Method | Electric Heating |
| Operating Temperature | 30-290°C |
| Temperature Accuracy | ±1°C |
| Menu Capacity | 300 Programs |
| Menu Programming Steps | Up to 15 steps per program |
| Cleaning Methods | 6 Fully Automatic Cleaning Modes |
| Meat Probe | Built-in 4-point temperature meat probe |
| Fan Type | Standard Fan with single speed setting |
| Steam (Humidity) Control | 10-100% Adjustable |
| Capacity | 6 x 2/3 GN |
| Daily Meal Capacity | 35-100 portions |
| Heating Power | 4.8 kW |
| Total Power Consumption | 4.85 kW |
| Total Current | 21A |
| Circuit Breaker Requirement | 25A |
| Power Supply | N-220V AC/50Hz/1PH |
| External Dimensions (mm) | 770 × 635 × 615 |
| Cavity Entrance Size (mm) | 395 × 350 |
| Water Inlet Diameter | 3/4" to 1/2" |
| Water Pressure | 0.2-0.5 MPa |
| Drain Pipe Diameter | 42mm |
| Net Weight | 75 kg |
| Gross Weight | 90 kg |
| Package Dimensions (mm) | 840 × 700 × 800 |
| Warranty | 2-Year Warranty (Excluding consumables such as glass, bulbs, door seals, etc.) |
Product Overview
The Axewood Mini 6-Tray Combi Oven delivers professional-grade versatility in a compact footprint, combining steam and convection cooking for precision results. Engineered with electric heating and 10-100% adjustable steam control, this intelligent oven maintains ±1°C temperature accuracy across a 30-290°C range. The user-friendly interface features 300 programmable recipes with 15-step sequencing, while the integrated 4-point meat probe ensures perfect doneness control.
Ideal for space-conscious kitchens, this unit accommodates 6 GN pans with a daily output of 35-100 meals. The energy-efficient 4.8kW system operates on standard 220V power, while six automated cleaning programs simplify maintenance. Perfect for bakeries, cafes, and small restaurants seeking advanced cooking technology in a practical size.
Key Features
-
Precision Cooking - ±1°C temperature accuracy with adjustable steam control
-
Smart Programming - 300 customizable recipes with multi-step sequencing
-
Professional Capacity - 6 GN pan capacity for 35-100 daily meals
-
Advanced Monitoring - 4-point meat probe for perfect results
- Easy Maintenance - 6 automated cleaning programs
Applications
-
Artisan Bakeries - Perfect for crusty breads and delicate pastries
-
Cafe Operations - Ideal for baked goods and light meals
-
Restaurant Kitchens - Versatile protein and vegetable preparation
- Catering Services - Efficient batch cooking for events
Operation & Support
Backed by 2-year warranty with complete documentation and technical support.
Product FAQ
What applications is Mini Combi Steam Oven 6-Layer 6-Tray for Cafes and Restaurants suitable for?
Mini Combi Steam Oven 6-Layer 6-Tray for Cafes and Restaurants is designed for commercial kitchens, central kitchens, restaurants, canteens and food processing projects. Final selection should be confirmed according to capacity, materials, site conditions, voltage and hygiene requirements.
Can this product be customized or supplied as OEM?
Customization such as voltage, dimensions, material grade, functions, logo and packaging can be evaluated when confirmed in writing. The final scope is subject to the quotation and order confirmation.
How are warranty, spare parts, returns or replacements handled?
Warranty, spare parts, return and replacement matters depend on product category, customization level, product condition and installation environment, and are subject to the final written documents and applicable laws.
How can I get an accurate quotation for HM-1?
Please provide the model, quantity, destination port or delivery location, power requirements, application scenario and expected delivery time. We will prepare a written offer based on configuration, packaging, transport and trade terms.
Product Details
Product Reference
- Product name: Mini Combi Steam Oven 6-Layer 6-Tray for Cafes and Restaurants
- SKU / Model code: HM-1
- Categories: Kitchen Equipment / Oven Equipment / Combi Steam Ovens
- Supplier: Huayi Smart Solutions
