20-Layer Universal Steam Oven 400-600 Portions Daily
SKU: HM-8
| Specification | Details |
|---|---|
| Model | 20-Layer 20-Tray Universal Steam Oven AWE-201DX-M2 |
| Brand | Axewood |
| Manufacturer | Guangzhou Golden Armor Catering Equipment Co., Ltd. (Sino-Joint Venture) |
| Place of Origin | Guangzhou, China |
| Heating Method | Electric Heating |
| Operating Temperature | 30-290°C |
| Temperature Accuracy | ±1°C |
| Menu Editor | 9 three-stage programmable menus |
| Cleaning Methods | 3 Fully Automatic Cleaning Modes |
| Meat Probe | Built-in 4-point temperature meat probe |
| Fan Type | Frequency Conversion Variable Speed Fan with 3 adjustable speeds |
| Capacity | 20 x 1/1 GN |
| Daily Meal Capacity | 400-600 portions |
| Heating Power | 32 kW |
| Total Power Consumption | 32.8 kW |
| Total Current | 49A |
| Circuit Breaker Requirement | 60A |
| Power Supply | 3N-380V AC/50Hz |
| Included | One rack-type trolley |
| External Dimensions (mm) | 935 × 795 × 1800 |
| Cavity Entrance Size (mm) | 609 × 1380 |
| Water Inlet Diameter | 3/4" to 1/2" |
| Water Pressure | 0.2-0.4 MPa |
| Drain Pipe Diameter | 42mm |
| Net Weight | 271.5 kg |
| Gross Weight | 311.5 kg |
| Package Dimensions (mm) | 1080 × 930 × 1980 |
| Warranty | 2-Year Warranty (Excluding consumables such as glass, bulbs, door seals, etc.) |
Product Overview
The Axewood AWE-201DX-M2 20-Layer Universal Steam Oven delivers industrial-scale cooking capacity for high-volume food production facilities. This heavy-duty combi oven combines a powerful 32kW heating system with precision temperature control, maintaining ±1°C accuracy across a 30-290°C operating range. The intelligent control system features 9 three-stage programmable menus and a built-in 4-point meat probe, while the frequency conversion fan with 3 adjustable speeds ensures optimal heat distribution for consistent results.
Key Features
-
Industrial Capacity - 20 GN pan capacity producing 400-600 meals daily
-
Precision Control - ±1°C temperature accuracy with programmable menus
-
Advanced Airflow - Frequency conversion fan with 3 speed settings
-
High-Power Performance - 32kW heating system for rapid operation
- Professional Features - Built-in meat probe and automated cleaning
Applications
-
Central Kitchens - Mass production for multiple outlets
-
Large Catering - Banquet and event services
-
Institutional Dining - Schools, hospitals, and corporate facilities
- Food Manufacturing - Batch production and development
Technical Advantages
-
Energy-efficient 32.8kW power consumption
-
Heavy-duty construction for continuous use
-
Three automated cleaning programs
-
Included rack trolley for operational efficiency
- Standard 380V 3-phase power compatibility
Operation & Support
Backed by 2-year warranty with complete documentation and professional technical support.
Product FAQ
What applications is 20-Layer Universal Steam Oven 400-600 Portions Daily suitable for?
20-Layer Universal Steam Oven 400-600 Portions Daily is designed for commercial kitchens, central kitchens, restaurants, canteens and food processing projects. Final selection should be confirmed according to capacity, materials, site conditions, voltage and hygiene requirements.
Can this product be customized or supplied as OEM?
Customization such as voltage, dimensions, material grade, functions, logo and packaging can be evaluated when confirmed in writing. The final scope is subject to the quotation and order confirmation.
How are warranty, spare parts, returns or replacements handled?
Warranty, spare parts, return and replacement matters depend on product category, customization level, product condition and installation environment, and are subject to the final written documents and applicable laws.
How can I get an accurate quotation for HM-8?
Please provide the model, quantity, destination port or delivery location, power requirements, application scenario and expected delivery time. We will prepare a written offer based on configuration, packaging, transport and trade terms.
Product Details
Product Reference
- Product name: 20-Layer Universal Steam Oven 400-600 Portions Daily
- SKU / Model code: HM-8
- Categories: Kitchen Equipment / Oven Equipment / Combi Steam Ovens
- Supplier: Huayi Smart Solutions
