Heavy-Duty SUS304 Stainless Steel Steam Sterilization Kettle 50-900kg Capacity

Heavy-Duty SUS304 Stainless Steel Steam Sterilization Kettle 50-900kg Capacity

SKU: HR-1

SUS304 stainless steel steam sterilization kettle for batch processing 50–900kg. Precise pressure (0.30MPa) and temperature (up to 147°C) control ensures reliable sterilization. Energy-efficient, durable, and easy to integrate with customer steam or air systems. Compact design fits small to large-scale food, beverage, pharmaceutical, and industrial production requiring hygiene and consistent results.

Minta sebut harga

Penerangan

Industrial Steam Sterilizer Kettle Model Options

Model	Tank Size Hot Water / Process	Capacity	Power	Weight	Dimensions L×W×H	Steam Requirement
700×1200mm	0.45m³ / 0.45m³	50–100kg	5.7kW	1000kg	2500×1000×1800mm	0.2–0.3T/0.7MPa
900×1800mm	1.1m³ / 1.1m³	200kg	5.7kW	2000kg	4100×1200×2500mm	0.3–0.5T/0.7MPa
1000×2400mm	2.2m³ / 2.2m³	400kg	9kW	2500kg	4500×2000×2800mm	0.5T/0.7MPa
1200×3600mm	4.45m³ / 4.45m³	900kg	12.5kW	3000kg	6500×2500×3100mm	1T/0.7MPa

Key Features

Premium SUS304 stainless steel construction ensures corrosion resistance hygiene and long term durability
Design pressure 0.35MPa working pressure 0.30MPa and max temperature 147°C for safe and efficient sterilization
High capacity batch sterilization from 50kg to 900kg to meet small medium and large production needs
Energy efficient operation reduces operational costs while maintaining consistent high performance
Flexible integration with customer supplied steam and compressed air systems for versatile production setups
Compact footprint with optimized tank design for easy installation and efficient workflow
Ideal for food beverage pharmaceutical and industrial sterilization applications where hygiene and reliability are critical

Detailed Model Comparison

700×1200mm model: ideal for small batch production 50–100kg with compact size 2500×1000×1800mm and 5.7kW power
900×1800mm model: mid size 200kg capacity suitable for restaurants and medium production facilities
1000×2400mm model: 400kg capacity for larger production with enhanced power 9kW and robust structure
1200×3600mm model: 900kg high capacity solution for industrial scale sterilization applications with 12.5kW power and reinforced 5mm tank thickness
