DQ370T-E Tabletop MAP Packaging Machine Modified Atmosphere Sealer

Name: DQ370T-E Tabletop MAP Packaging Machine Modified Atmosphere Sealer
Brand: Huayi Smart Solutions
SKU: HB-17

SKU: HB-17

The DQ370T-E Tabletop MAP System combines industrial-grade performance with space-efficient design, delivering exceptional gas flushing precision in a compact footprint. Achieving laboratory-level accuracy with ≥99% gas replacement rate and ±2% mixing precision, this advanced system maintains 5-6 cycles per minute while handling multiple tray configurations through its innovative 4-outlet design.

Get a Quote

Product Details

Gas Displacement	Main Configurations	Main Configurations	Main Configurations
Equipment Model	DQ370T-E	Dasheng Core Modified Atmosphere Technology	Dasheng Independent Core Technology
Max. Roll Film Width (mm)	370	Main Structure & Housing	Stainless Steel
Max. Roll Film Diameter (mm)	200	Mold Part	6061 Aluminum
Gas Replacement Rate	≥99%	Photoelectric Sensor (Length Measuring)	Dasheng Self-developed
Gas Mixing Accuracy (%)	Fluctuation ±2%	Photoelectric Sensor (Cursor Film)	Xinling Electric
Packaging Speed (times/min)	5～6	DC Power Supply	Delta
Production Capacity (boxes/hour) - 1-out	≈360	Air Cylinder	Tianqi
Production Capacity (boxes/hour) - 2-out	≈640	Solenoid Valve	Airtac (Taiwan)
Production Capacity (boxes/hour) - 4-out	≈1200	Touch Screen	Kunlun Tongtai
Power Supply (V/Hz)	220/50	Film Rewinding Motor	Taisong
Total Power (kW)	2.1	Control System	Dasheng Intelligent Self-developed Control System
Working Air Pressure (Mpa)	0.6～0.8	Power Switch	Delixi
Equipment Weight (kg)	89	Relay	Delixi
Equipment Dimension LWH (mm)	1045950665	Fuse Holder	Delixi
Packaged Gross Weight (kg)	197	Cartridge Cylinder	Tianqi
Anneng Volumetric Weight (kg)	197	Temperature Controller	Takahashi
Outer Carton Dimension LWH (mm)	10701070860
Max. Tray Size (mm) - 2-out	31020080 (*2)
Max. Tray Size (mm) - 4-out	20014080 (*4)

Product Overview

The DQ370T-E Tabletop Modified Atmosphere Packager brings industrial-grade preservation technology to compact workspaces, achieving laboratory-level gas replacement rates of ≥99% with remarkable ±2% accuracy. This sophisticated system combines robust stainless steel construction with precision 6061 aluminum molds, delivering consistent 5-6 cycles per minute across multiple tray configurations. Equipped with Delta power components, Airtac pneumatic valves, and an intuitive Kunlun Tongtai touchscreen, it makes advanced MAP packaging accessible for specialty food producers, gourmet kitchens, and small-batch manufacturers seeking to extend product freshness with professional reliability.

Key Features

Advanced Gas Control - Maintains ≥99% gas replacement rate with ±2% precision for optimal freshness preservation
Space-Smart Design - Compact 1045×950×665mm footprint integrates seamlessly into limited production areas
Professional Components - Features Delta power supply, Airtac valves, and self-developed photoelectric sensors
Multi-Output Efficiency - Processes up to 1,200 packages hourly through flexible 2-out and 4-out configurations
Intelligent Operation - User-friendly touchscreen interface with self-developed control system

Applications

Specialty Foods - Ideal for artisan cheeses, premium cuts, gourmet prepared meals
Fresh Produce - Perfect for organic vegetables, fruits, and salad mixes
Small-Batch Production - Excellent for craft food businesses and local producers
Retail Ready Packaging - Suitable for boutique markets and specialty food stores

Technical Advantages

Consistent gas flushing performance across all production cycles
Rapid changeover between different tray sizes and formats
Energy-optimized operation at 2.1kW power consumption
Durable stainless steel construction ensures long service life
Compatible with various film types and packaging materials

Product FAQ

What applications is DQ370T-E Tabletop MAP Packaging Machine Modified Atmosphere Sealer suitable for?

DQ370T-E Tabletop MAP Packaging Machine Modified Atmosphere Sealer is designed for commercial kitchens, central kitchens, restaurants, canteens and food processing projects. Final selection should be confirmed according to capacity, materials, site conditions, voltage and hygiene requirements.

Can this product be customized or supplied as OEM?

Customization such as voltage, dimensions, material grade, functions, logo and packaging can be evaluated when confirmed in writing. The final scope is subject to the quotation and order confirmation.

How are warranty, spare parts, returns or replacements handled?

Warranty, spare parts, return and replacement matters depend on product category, customization level, product condition and installation environment, and are subject to the final written documents and applicable laws.

How can I get an accurate quotation for HB-17?

Please provide the model, quantity, destination port or delivery location, power requirements, application scenario and expected delivery time. We will prepare a written offer based on configuration, packaging, transport and trade terms.

Product Details

Product Reference

Product name: DQ370T-E Tabletop MAP Packaging Machine Modified Atmosphere Sealer
SKU / Model code: HB-17
Categories: Packaging Machine / MAP Packaging Machine / Modified Atmosphere Packaging Machine
Supplier: Huayi Smart Solutions
