EA Series Nitrogen Generator 1.5-10Nm³/h for Small Packaging Plants
SKU: HB-285
| Specification | 1.5EA | 2EA | 3EA | 5EA | 8EA | 10EA |
|---|---|---|---|---|---|---|
| Model | 1.5EA | 2EA | 3EA | 5EA | 8EA | 10EA |
| Nitrogen Output | 1.5 Nm³/h | 2 Nm³/h | 3 Nm³/h | 5 Nm³/h | 8 Nm³/h | 10 Nm³/h |
| Nitrogen Purity | 99.9% | 99.9% | 99.9% | 99.9% | 99.9% | 99.9% |
| Feed Pressure | 0.7–0.8 MPa | 0.7–0.8 MPa | 0.7–0.8 MPa | 0.7–0.8 MPa | 0.7–0.8 MPa | 0.7–0.8 MPa |
| Nitrogen Pressure | 0–0.65 MPa | 0–0.65 MPa | 0–0.65 MPa | 0–0.65 MPa | 0–0.65 MPa | 0–0.65 MPa |
| Pressure Dew Point | -10°C | -10°C | -10°C | -10°C | -10°C | -10°C |
| Total Weight | 40 kg | 50 kg | 70 kg | 85 kg | 110 kg | 155 kg |
| Dimensions (L×W×H) | 290×670×950 mm | 290×670×950 mm | 280×670×1160 mm | 430×670×950 mm | 430×670×1460 mm | 430×670×1460 mm |
| Case Material | SUS 201 | SUS 201 | SUS 201 | SUS 201 | SUS 201 | SUS 201 |
EA Series Nitrogen Generator
The EA series nitrogen generator is developed for food-grade applications that require a compact and cost-effective on-site nitrogen solution. It delivers stable nitrogen performance for small to medium food processing and packaging operations.
Reliable Nitrogen Purity for Food Use
Providing nitrogen purity of 99.9%, the EA series helps reduce oxygen levels during food packaging and handling. This supports freshness preservation and slows oxidation in a wide range of food products.
Flexible Output Options
With nitrogen output capacities from 1.5 to 10 Nm³/h, the EA series can be selected to match different production speeds, making it suitable for both small packaging stations and growing food operations.
Controlled Moisture Content
A pressure dew point of –10°C ensures reduced moisture in the nitrogen stream, supporting stable operation and helping protect packaging quality in food environments.
Compact Stainless Steel Design
The space-saving cabinet and SUS 201 stainless steel enclosure provide durability and resistance to humidity commonly found in food processing areas, while allowing easy cleaning and maintenance.
Simple Installation and Integration
Operating with standard feed and output pressure ranges, the EA nitrogen generator integrates easily with existing food packaging equipment, helping improve workflow efficiency.
Food Industry Applications
The EA series nitrogen generator is suitable for bakeries, snack food packaging, ready-to-eat meals, meat and seafood processing, and other food facilities requiring dependable nitrogen supply.
